How to launch and use Amazon EKS

Amazon EKS is a managed service that helps make it easier to run Kubernetes on AWS. Through EKS, organizations can run Kubernetes without installing and operating a Kubernetes control plane or worker nodes. Simply put, EKS is a managed containers-as-a-service (CaaS) that drastically simplifies Kubernetes deployment on AWS.

With Amazon EKS, the Kubernetes control plane — including the backend persistence layer and the API servers — is provisioned and scaled across various AWS availability zones, resulting in high availability and eliminating a single point of failure. Unhealthy control plane nodes are detected and replaced, and patching is provided for the control plane. The result is a resilient AWS-managed Kubernetes cluster that can withstand even the loss of an availability zone.

Amazon EKS Features

The main benefit of using Amazon EKS is that organizations can take full advantage of the reliability, availability, performance, and scale of the AWS platform, essential to which are integrations with AWS security and networking services.

• Managed Control Plane
• Managed Worker Nodes
• Service Discovery
• VPC Support
• Load Balancing
• Managed Cluster Updates

Steps to Set Up Amazon EKS

Getting started with Amazon EKS is straightforward, but it does come with a short list of prerequisites. If you’ve been running on AWS for quite a while, chances are you already have the prerequisite components set up.

Prerequisites

The following components must be installed and set up on your AWS account before you can get started with Amazon EKS:

1. Kubectl
2. AWS CLI
3. AWS-IAM-Authenticator

Create the IAM Role

1. Open the IAM console
2. Choose Roles > Create role
3. Select EKS from the list > choose Allows Amazon EKS to manage your clusters on your behalf for your use case> Next: Permissions

4. Click Next: Tags.

5. Click Next: Review

Create Amazon EKS Cluster

This will create eks cluster with 3 nodes of t2.micro for us. You can choose according to your requirement

apiVersion: eksctl.io/v1alpha5
kind: ClusterConfig
metadata:
  name: ekscluster
  region: ap-south-1
nodeGroups:
  - name: node1
    desiredCapacity: 3
    instanceType: t2.micro
    ssh:
      publicKeyName: eks

We can see that 3 instance are launched according to what we asked

Creating EFS for storing data

VPC is automatically created after cluster is created. Using that VPC we create our EFS.

Creating EFS Provisioner

kind: Deployment
apiVersion: apps/v1
metadata:
  name: efs-provisioner
spec:
  selector:
    matchLabels:
      app: efs-provisioner
  replicas: 1
  strategy:
    type: Recreate
  template:
    metadata:
      labels:
        app: efs-provisioner
    spec:
      containers:
        - name: efs-provisioner
          image: quay.io/external_storage/efs-provisioner:v0.1.0
          env:
            - name: FILE_SYSTEM_ID
              value: fs-1d9f15cc
            - name: AWS_REGION
              value: ap-south-1
            - name: PROVISIONER_NAME
              value: eks/aws-efs
          volumeMounts:
            - name: pv-volume
              mountPath: /persistentvolumes
      volumes:
        - name: pv-volume
          nfs:
            server: fs-1d9f15cc.efs.ap-south-1.amazonaws.com
            path: /

Replace the File system ID with the ID you get from EFS service page in the AWS management console or we can print the same through the Terraform code. Also, replace the server.

Modifying RBAC

apiVersion: rbac.authorization.k8s.io/v1beta1
kind: ClusterRoleBinding
metadata:
  name: nfs-provisioner-role-binding
subjects:
  - kind: ServiceAccount
    name: default
    namespace: thegreat
roleRef:
  kind: ClusterRole
  name: cluster-admin
  apiGroup: rbac.authorization.k8s.io

We have created a YML code to modify some permisssions using ROLE BASED ACCESS CONTROL (RBAC).

Creating Storage Class

kind: StorageClass
apiVersion: storage.k8s.io/v1
metadata:
  name: aws-efs
provisioner: eks/aws-efs
---
kind: PersistentVolumeClaim
apiVersion: v1
metadata:
  name: efs-jenkins
  annotations:
    volume.beta.kubernetes.io/storage-class: "aws-efs"
spec:
  accessModes:
    - ReadWriteMany
  resources:
    requests:
      storage: 5Gi
---
kind: PersistentVolumeClaim
apiVersion: v1
metadata:
  name: efs-mysql
  annotations:
    volume.beta.kubernetes.io/storage-class: "aws-efs"
spec:
  accessModes:
    - ReadWriteMany
  resources:
    requests:
      storage: 5Gi

Deployments

MySQL

apiVersion: apps/v1 # for versions before 1.9.0 use apps/v1beta2
kind: Deployment
metadata:
  name: jenkins-mysql
  labels:
    app: jenkins
spec:
  selector:
    matchLabels:
      app: jenkins
      tier: mysql
  strategy:
    type: Recreate
  template:
    metadata:
      labels:
        app: jenkins
        tier: mysql
    spec:
      containers:
      - image: mysql:5.7
        name: mysql
        env:
        - name: MYSQL_ROOT_PASSWORD
          valueFrom:
            secretKeyRef:
              name: confidential
              key: sqlrootpassword
        - name: MYSQL_USER
          valueFrom:
            secretKeyRef:
              name: confidential
              key: sqluser
        - name: MYSQL_PASSWORD
          valueFrom:
            secretKeyRef:
              name: confidential
              key: sqlpassword
        - name: MYSQL_DATABASE
          valueFrom:
            secretKeyRef:
              name: confidential
              key: sqldb
        ports:
        - containerPort: 3306
          name: mysql
        volumeMounts:
        - name: mysql-ps
          mountPath: /var/lib/mysql
      volumes:
      - name: mysql-ps
        persistentVolumeClaim:
          claimName: efs-mysql

Jenkins

apiVersion: apps/v1 # for versions before 1.9.0 use apps/v1beta2
kind: Deployment
metadata:
  name: jenkins
  labels:
    app: jenkinso
spec:
  selector:
    matchLabels:
      app: jenkinso
      tier: deploy
  strategy:
    type: Recreate
  template:
    metadata:
      labels:
        app: jenkinso
        tier: deploy
    spec:
      containers:
      - image: jenkins
        name: jenkins
        env:
        - name: JENKINS_SLAVE_AGENT_PORT
          valueFrom:
            secretKeyRef:
              name: jen
              key: dcpassword
        - name: database_connection_database
          valueFrom:
            secretKeyRef:
              name: mysecret
              key: slave
        ports:
        - containerPort: 8080
          name: jenkins
        volumeMounts:
        - name: jenkins-ps
          mountPath: /var/jenkins_home
      volumes:
      - name: jenkins-ps
        persistentVolumeClaim:
          claimName: efs-jenkins

Output

And Our whole setup is ready

For queries or suggestions you can DM

Rajnish-TheGreat/eks
